Dometic CoolAir RTX-SPXT-IK - Universal installation kit 1 - screw fastening
The Dometic CoolAir RTX-SPXT-IK universal installation kit 1 uses screw fastening to mount RTX 1000, RTX 2000 and SPX 1200T units in an existing cab roof hatch.
Screw fastening through the existing hatch
This kit uses a perforation attachment system at the factory roof ventilation opening, rather than the cross-bracket arrangement used by universal kit 2.
Roof slope and clearance
The maximum forward roof slope at the mounting surface is 8° for RTX 1000 and 20° for RTX 2000, and 17° for SPX 1200T. Keep the external ventilation openings unobstructed, with at least 100mm clearance from other roof attachments.
Whatâs included
- Cover frame to finish the cab interior
- Installation material
- 2.7m sealing strip, 10 x 20mm profile
- 2.7m sealing strip, 35 x 20mm profile
- 4m connection cable, 6mm²
- Installation manual
Looking for an air con unit?
View our full range of air con units âī¸
Products that give back
For every product purchased from Nohma, we make a donation to The Honnold Foundation, to provide solar power to underprivileged communities. If you want your electrical system to have more of a positive impact, purchasing your components from us at Nohma will mean you can give back as well as powering your off-grid system.
Product SKU: 9100300151
