Scanstrut Roam - Universal Electrical and Utility Housing - SC-R-U1
The Scanstrut Roam Universal Electrical and Utility Housing gives you a blank enclosure for adding a bespoke external connection whilst keeping the same exterior design as the rest of the Roam range. Scanstrut suggests uses including switches, circuit breakers, outlets, chargers, cable feed-throughs, air compressor quick-connectors, monitoring points and water pump switches.
The usable internal installation area is up to 70.4mm wide and 78.4mm high, with a maximum internal installation depth of 22.5mm. The housing itself has an installation depth of 15mm and uses 3mm PC/ABS material rated UL94 V-0.
This housing is intended for low-voltage AC / DC applications and is not suitable for drinking water contact. If it is installed alongside water connections, Scanstrut specifies switches and wiring rated to at least IPX6.
Features of the Scanstrut Roam Universal Electrical and Utility Housing
- Fully customisable blank housing
- Suitable for bespoke switches, sockets, chargers and cable entries
- IP68 / IP69K with the cover closed
- Marine-grade 316 stainless steel hardware
- Fully sprung lid with 90 degree hold-open feature
- Mounting foam gasket included
- Scanstrut describes it as smallest in class
- Requires a 95mm hole saw for installation
Products that give back
For every product purchased from Nohma, we make a donation to The Honnold Foundation, to provide solar power to underprivileged communities. If you want your electrical system to have more of a positive impact, purchasing your components from us at Nohma will mean you can give back as well as powering your off-grid system.
Product SKU: SC-R-U1 / 121649
