Victron MPPT 100/20 – BlueSolar Charge Controller

£157.44 £76.60 Save 51%

The Victron MPPT 100/20 BlueSolar charge controller harvests the power generated from your solar panels and intelligently charges your leisure batteries. All Victron MPPT charge controllers perform this function efficiently whilst protecting your leisure batteries from overcharging.

  • For use in 12V and 24V systems
  • 100V maximum voltage from the solar array
  • 20A maximum current from the solar array
  • MPPT optimised for efficient solar charging
  • The BlueSolar series cannot be monitored through the VictronConnect app

Sorry, this product is not available to purchase in your country.

SKU: SCC110020170R Category:

£0.77 of this purchase goes to planting trees and advancing access to solar energy 🌱
Find out more

Campervan electrics leaving you confused?

Our team of engineers will design your perfect system, bespoke to your needs 👌
Discover more It's free

    Victron Energy MPPT 100/20 – BlueSolar Charge Controller – SCC110020170R

    Charge controllers intelligently collect energy from the sun and convert it into power for your electrical system. Using the latest, fastest technology, BlueSolar optimises this energy harvest, intelligently achieving full charge in the shortest possible time. BlueSolar also maintains battery health, extending battery life. The Victron MPPT 100/20 BlueSolar model has a maximum input voltage of 100V and a maximum input current of 20A.

    Victron MPPT 100/20 charge controller

    By constantly monitoring the voltage and current output of your solar (PV) panels, MPPT technology wrings every drop of available power out of your panels. The advantage of this is most noticeable when the sky is partially clouded, and light intensity is constantly changing. MPPT charge controllers are much more efficient than PWM charge controllers and we recommend them for most off-grid applications such as campervans, boats and off-grid tiny houses.

    Smart functionality

    The BlueSolar range of MPPT chargers do not have Bluetooth and so cannot be wirelessly monitored. If you would like to monitor your Victron charge controller via your phone, please see the range of SmartSolar MPPT charge controllers.

    Load output

    The intelligent load output function prevents damage caused by running batteries ‘flat’. You can configure the voltage at which BlueSolar disconnects a load – thereby preventing excessive drain on your batteries. And here’s the clever bit: SmartSolar will attempt a 100% recharge every day. If it can’t – during periods of poor weather – it raises the disconnect voltage, daily, until it achieves success. We call this feature BatteryLife because it maintains the health of your battery and extends its life.

    Connection Points

    This charge controller has Tr screw terminal connection points, so you will need to strip your input and output wires of a short length of insulation to fix them to the screwed terminal.

    Looking for a different rated Victron Energy MPPT charge controller?

    View the full range of Victron MPPT charge controllers, rated from 75/10-150/45.

    Products that give back

    We are members of 1% for the Planet. This means that for every product purchased from Nohma, 1% of the total cost will be given to The Honnold Foundation, to provide solar power to underprivileged communities. If you want your electrical system to have more of a positive impact, purchasing your components from us at Nohma will mean you can give back as well as powering your off-grid system.

    Product SKU: SCC110020170R


    Weight 0.7 kg
    Dimensions 10 × 11.3 × 5 cm
    Brand

    Victron Energy

    Manufacturer Part Number

    SCC110020170R

    Voltage

    12V or 24V

    Charge controller rating

    100/20

    Rated Charge Current

    20A

    Nominal PV Power @ 12V

    290W

    Max. PV Open Circuit Voltage

    100V

    Max Efficiency

    98%

    IP Rating

    IP43 (electronic components), IP22 (connection area)

    Warranty

    5 years

    Smart functionality

    Non-smart

    Product or kit

    Product

    Charge controller type

    MPPT
