400W Flexible Solar Panel Kit – Includes Victron MPPT & 2x 200W Flexible Panels

From £1,132.21

This 400W flexible solar panel kit includes everything you need to wire two 200W flexible solar panels and a 100/30 MPPT charge controller as part of your 12V campervan electrical system. It includes:

  • 2 x 200W black flexible solar panel
  • 100/30 smart MPPT charge controller
  • Solar cable to connect solar panels to charge controller (choose the distance between your solar panels & charge controller)
  • Required DC cable, cable lugs & fuses
  • Isolator switch
  • Double-entry cable seal

Please note: Lynx Distributor / busbars are not included in this kit. Selecting which one you plan to use allows us to include the necessary fuses.

From £1,132.21

One percent of this purchase goes to planting trees and advancing access to solar energy 🌱
Find out more

Got a question or want to modify a kit?

Our team of engineers can tailor any kit to your needs, by email or phone 👌
Book a call

Want to modify a kit?

Fill out the form below and one of our engineers will be in touch soon.

"*" indicates required fields

Name*
Please let us know how you would like to modify this kit and an engineer will be in touch shortly.
This field is for validation purposes and should be left unchanged.

    400W Flexible Solar Panel Kit – Includes Victron MPPT, 2 x 200W Flexible Solar Panels & all required components

    This 12V 400W flexible solar panel kit includes everything you need to wire a 400W solar array and a 100/30 MPPT charge controller as part of your campervan electrical system. It includes:

    Plus, pick from the following variables:

    • Victron solar cable length – select the distance between your solar panels and your charge controller

    400W solar panel kit

    Our solar panel kits include everything you need to connect a solar system to your electrical system. All cabling, fuses, cable lugs, etc. are included, as well as a number of optional extras to enhance the system.

    This kit includes two of our 200W flexible solar panel. This is a monocrystalline solar panel with a Voc of 20.8V and an Isc of 12.05A. Note that this Voc will double when these panels are wired in series, as instructed in the attached wiring diagram.

    The 100/30 charge controller is suitable for the supplied solar panel. The SmartSolar version is included with this kit.

    The DC cable gauge is specced on the distance between the charge controller and your busbars being no longer than 1.5m each way (3m ‘there and back again’ length). If your charge controller will be further away than this, please contact us via the ‘modify this kit’ section above so we can provide a system proposal with the correct cable gauge.

    We include a PV isolator switch in every kit. This allows you to easily isolate the subsystem from the rest of your electrical system.

    We include a Scanstrut horizontal double-entry cable seal with each kit. Scanstrut make rugged and weatherproof entry glands which provide a sealed and secure entry point into your van for the solar panel cables.

    We use Victron solar cable to connect the solar panels to the charge controller. Select the distance between your solar panels and charge controller, and we will supply a cable twice as long. This is then cut in half to create 2x cables with an MC4 connector at one end and wire at the other end.

    Select whether you will use busbars or a Lynx Distributor to connect your subsystems to your batteries. Please note that the busbars / Lynx Distributor are not included in this kit, however by selecting what you are using in your system, we can ensure we include the required fuses and fuse holders.

    Wiring diagram & installation guidance

    All of our kits are supplied with a subsystem wiring diagram and installation guidance. This includes information on setting up the charge controller correctly using the rotary switch and the VictronConnect app (if a SmartSolar charge controller is selected). So, you can install your system easily and be confident it’s installed correctly. If you need any support during the installation, contact us and we can provide additional support.

    Looking for a different solar panel kit?

    View the full range of solar panel kits ☀️

    400W solar array – use case

    A 400W solar array is suitable for a medium-sized off-grid electrical system, such as in a campervan with medium power usage. For example, a 400W solar array would fully recharge a 300Ah AGM battery bank (3 x 100Ah batteries) from 20%-100% in ~11 hours on a sunny summer’s day.

    Products that give back

    We are members of 1% for the Planet. This means that for every product purchased from Nohma, we will give 1% of the total cost to The Honnold Foundation, who provide solar power to underprivileged communities. If you want your electrical system to have more of a positive impact, purchase your components from Nohma. So, you can give back as well as powering your off-grid system.


    Weight 3.65 kg
    Dimensions 142 × 71 × 2 cm
    Distance from panels to charge controller

    Up to 2.5m, Up to 5m, Up to 9m

    Connection type

    Busbar (not included), Lynx Distributor (not included)

    Charge controller

    SmartSolar (smart)

    Voltage

    12V

    Solar array size (W)

    200

    Cell type

    Monocrystalline

    Solar panel type

    Flexible

    Solar panel colour

    Traditional

    Junction box position

    Front

    Open Circuit Voltage (Voc)

    20.8V

    Short circuit current (Isc)

    12.05A

    Maximum power voltage (Vmpp)

    17.6V

    Maximum power current (Impp)

    11.36A

    Warranty

    2 years

    Product or kit

    Kit
