600W Solar Panel Kit – Includes Victron MPPT, 3x 200W rigid rectangular solar panel & all required components
This 12V 600W solar panel kit includes everything you need to wire a 600W solar array and a 100/50 MPPT charge controller as part of your campervan electrical system. It includes:
- 3 x 200W rigid solar panels
- Required DC cable, cable lugs & fuses
- PV isolator switch
- Scanstrut cable seal
Plus, pick from the following variables:
- Charge controller – pick from the 100/50 SmartSolar or the 100/50 BlueSolar (non-smart)
- Victron solar cable length – select the distance between your solar panels and your charge controller
- Solar panel brackets – select glued brackets or screwed brackets
600W solar panel kit
Our solar panel kits include everything you need to connect a solar array to your electrical system. We include all cabling, fuses, cable lugs, etc., as well as a number of optional extras to enhance the system.
This kit includes three 200W solar panels. This a monocrystalline solar panel with a Voc of 45V and an Isc of 5.8A. Note that this Isc will triple when these panels are wired in parallel, as instructed in the attached wiring diagram.
The 100/50 charge controller is suitable for the supplied solar panels. You can pick from the SmartSolar or the BlueSolar (non-smart) version.
The DC cable gauge is specced on the distance between the charge controller and your busbars being no longer than 1.5m each way (3m ‘there and back again’ length). If your charge controller will be further away than this, please contact us via the ‘modify this kit’ section above so we can provide a system proposal with the correct cable gauge.
We include a PV isolator switch in every kit. This allows you to easily isolate the subsystem from the rest of your electrical system.
We include a Scanstrut horizontal double-entry cable seal with each kit. Scanstrut make rugged and weatherproof entry glands which provide a sealed and secure entry point into your van for the solar panel cables.
We use Victron solar cable to connect the solar panels to the charge controller. Select the distance between your solar panels and charge controller, and we will supply a cable twice as long. This is then cut in half to create 2x cables with an MC4 connector at one end and wire at the other end.
Select from either glued or screwed solar panel brackets, and we’ll include the correct quantity for the solar panels in the kit. If you select screwed brackets, we’ll include well nuts to form a watertight connection. The well nut included is an M5 well nut, provided with a rubber washer and a BZP 25mm allan bolt.
Select whether you will use busbars or a Lynx Distributor to connect your subsystems to your batteries. Please note that the busbars / Lynx Distributor are not included in this kit, however by selecting what you are using in your system, we can ensure we include the required fuses and fuse holders.
Wiring diagram & installation guidance
We supply all of our kits with a subsystem wiring diagram and installation guidance. This includes information on setting up the charge controller correctly using the rotary switch and the VictronConnect app (if a SmartSolar charge controller is selected). So, you can install your system easily and be confident it’s installed correctly. If you need any support during the installation, contact us and we can provide additional support.
Looking for a different solar panel kit?
View the full range of solar panel kits ☀️
600W solar array – use case
A 600W solar array is suitable for a large-sized off-grid electrical system, such as in a campervan with high power usage. For example, a 600W solar array would fully recharge a 432Ah AGM battery bank (2 x 216Ah batteries) from 10%-100% in ~11 hours on a sunny summer’s day.
